Our mission: Your success
Delivering better instruments to make your working life easier
When it comes to accurate laboratory measurements of Total Organic Carbon (TOC) and Total Bound Nitrogen (TNb) in environmental and waste waters, our mission is to make your work as stress-free and efficient as possible. Our enviro TOC system combines proven analytical functionality with the latest technology requirements of the industry for the most convenient and resource-saving TOC and TNb determinations.
Counting on carbon - TOC vs. BOD & COD
Whitepaper
Learn why total organic carbon (TOC) measurement is the safer, more reliable and environmentally friendly alternative to biological and chemical oxygen demand (BOD and COD) measurement in wastewater analysis in this white paper.
DOWNLOAD YOUR COPY
Fill in the form to receive your download link by e-mail.
By clicking on the "Subscribe" button, I consent to the receipt of personalized newsletters via e-mail by Elementar Analysensysteme GmbH and its group companies companies as well as the evaluation of my user behavior in this regard and - if available - the merging of this data with my data in our customer database. In order to receive newsletters from our group companies, it is necessary to transfer your above-mentioned personal data to these companies. We point out that these are partly located in so-called unsafe third countries outside the EU/EEA , in which no adequate level of data protection (e.g. by adequacy decision of the EU, Art. 45 GDPR) is guaranteed. In these countries, you may not be able to enforce your rights as a data subject, or only to a limited extent. In addition, it is possible that local government agencies access your data to a disproportionate extent. The transfer of data to these recipients is therefore only legitimized by your consent pursuant to Art. 49 (1) lit. a) GDPR, which you grant with your subscription. The newsletter can be unsubscribed at any time with effect for the future as well as my consent to the third country transfer can be revoked at any time. A revocation does not affect the lawfulness of the processing carried out on the basis of the consent until the revocation. For further information, please refer to our privacy policy.
Watch our webinars
Our TOC specialists have produced a series of webinars packed with helpful advice, information and techniques for you to better understand and utilise TOC and TNb analysis in your laboratory.
Wastewater analysis
NEW CHALLENGES IN EVERYDAY LABORATORY WORK
TOC and TNb are important indicators in the process of wastewater treatment. There are now a number of regulations, both in the EU and worldwide, that define the permissible values for TOC and TNb from wastewater treatment plants. In our laboratory surveys, accurate analysis of TOC and TNb levels in particularly saline solutions, particulate-containing samples and solids were among the biggest challenges. Large, stable particles must be digested, saline samples lead to corrosion, and sedimentation and ash deposits cause increased and usually complicated maintenance. To fully digest these samples and ensure high quality results, these samples may need to be exposed to a range of different combustion temperatures.
Learn about the influence combustion temperature has on TOC determination in surface and wastewater, and how you can solve these and other challenges more quickly and conveniently.
Surface water analysis
On a mission to protect our most important resource
Monitoring the water quality of inland waters such as lakes, rivers, streams and ponds or of coastal waters and seawater is important for maintaining our quality of life and health. In this context, environmental laboratories are often faced with the challenge of analyzing not only liquid samples but also solids, for example sediments or soil samples. The flexible extension of measurement results (TOC, TC, TIC, NPOC, DOC) to include simultaneous TNb determination using efficient EC cell technology or a modern, integrated chemiluminescence detector (CLD) is also a requirement we frequently encounter in our discussions. The advantage of the CLD is linearly calibrated, stable measured values, which greatly simplifies calibration and result evaluation. The previous solution in the form of space- and time-consuming second or third devices is not an option, especially in smaller laboratories.
Find out now how a flexible, space-saving and cost-effective single-device solution can make your daily laboratory routine more efficient and convenient.
enviro TOC
Fully automated environmental and wastewater analysis
enviro TOC is specifically designed to be easier to use, more flexible, accurate and simpler to maintain. enviro TOC is a customizable system for TOC/TNb analysis in environmental water and wastewater. It is a future-oriented, precise technological solution that is also more efficient and environmentally friendly, thanks to longer-life components and a user-oriented maintenance concept. Regardless of whether you’re analyzing water from rivers, lakes and seas, or managing water from public sources, manufacturing processes and wastewater, enviro TOC is the smart choice.
Measuring TOC is easy
Our Benefits
Fully automated environmental & wastewater analysis
The autosampler of the enviro TOC even even enables unattended night operation with the highest precision. This is realized by the intuitive and innovative lyticOS® Software Suite. Optimized for unsupervised use, it actively assists you with self-diagnosis, automatic sleep and wake functions, visual guidance for maintenance tasks and full remote control functionality. This means you can rely on enviro TOC to provide the results you need when you need them and fits perfectly into a modern, high-throughput laboratory environment. For more information and to join our Elementar TOC Mission, click here.
FLEXIBILITY WHERE YOU NEED IT MOST
When you need to switch quickly to adapt to different sample types and parameters, enviro TOC has you covered. Fast conversion from liquids to solids in just a few minutes provides high flexibility and combustion temperatures of up to 1,200 °C crack even stable carbon compounds. If it’s lower temperatures you need, 700 °C for salt-containing samples can be defined. Learn more about the influence of the combustion temperature on TOC determination in our Application Note.
All of these features and more help enviro TOC fulfil our mission to make your environmental and wastewater analysis easier and more flexible. Contact our sales team for a personal consultation.
UNPARALLELED ACCURACY
enviro TOC’s high performance combustion provides accurate and dependable results every time. Rinsing functions for the needles on the autosampler and on the cleaning the tubes before the combustion unit minimize carryover, avoid sedimentation and contamination, providing even better data. This also increases the lifespan of the injection unit. The lyticOS® software suite works just as hard, helping to provide precise results by minimizing potential errors from incorrect usage. Results are processed immediately, and the calibration procedure is simplified, which makes TOC analysis easier for every operator.
Get in touch with our team to experience how enviro TOC can make a real difference for you and your lab.
EASY AND INTUITIVE MAINTENANCE
enviro TOC is a surface and wastewater analysis solution designed around you, the user. Most of the maintenance work can be performed without the need to consult a service engineer, thanks to video examples and clear explanations of procedures. Everything you need to know is covered by the ‘Elementar Academy’ – our user-centered training platform. enviro TOC’s unique maintenance concept goes a long way in providing you with greater piece of mind and achieving our aim to make your working life easier.
Find out more about enviro TOC from our sales team.
OPTIMIZED OPERATIONAL EXPENDITURE
enviro TOC doesn’t just provide high performance surface and wastewater analysis, it does that while keeping costs low at the same time. While gas and consumables consumption depends on the mode of operation and sample material, enviro TOC provides lower cost per analysis across the board.
For example:
- Regular rinsing with water keeps the wear of the injection needles and the 4-way valve low.
- 2 ml of 10% H3PO4 is typically needed for TIC analysis.
- 0.5 – 1 ml of 10% HCl is required for NPOC analysis.
- 175 ml/min of synthetic air or oxygen is needed for regular analysis, plus 90 ml/min for purging in NPOC mode, TIC mode and for the autosampler rinsing function.
WE'RE HERE FOR YOU
To keep your enviro TOC working as it should, we’re only a phone call, email or message away. Our dedicated global service team is there for you and your device, helping to ensure maximum uptime and optimal performance under all circumstances.
To increase the service life and functionality, we also offer customized maintenance contracts and certified consumables as well as high quality spare parts. Just get in touch if you need us.
Experience enviro TOC in the laboratory
The right method for every application
Downloads
Discover the best methods, useful hints and expert tips for your very specific applications in TOC analysis.
Stay up-to-date
Newsletter
Further downloads are coming soon.
Stay up-to-date and register for our newsletter to receive latest news and publications on surface water and wastewater analysis.
Our TOC Mission team is here for you
On-site or online
Do you have questions or challenges and need an expert to provide straightforward support? You are evaluating different methods and need our help? You want to learn more about our mission? Our TOC Mission team is available to answer all your questions about surface and wastewater analysis.
